Honeywell 2-Way Motorized Valve with Actuator | 1 Inch | VC6013AP1000T

Description
The Honeywell VC6013AP1000T is a 2-way motorized hydronic valve designed for precise ON/OFF zone control in domestic and light commercial heating or cooling applications. It consists of an actuator, valve body, and cartridge assembly, making it compact, reliable, and easy to service.

This valve is ideal for controlling fan coil units, radiators, space heaters, or convectors, and can be operated with low or line voltage SPST/SPDT controllers such as thermostats, aquastats, or flow switches. The VC Series actuator travel uses sinusoidal motion, ensuring silent operation and reduced water hammer.

With a removable actuator head for easy servicing (without draining the system) and interchangeable actuator versions, it offers maximum flexibility and efficiency in HVAC system design and maintenance.

Key Points
⦁ 2-Way ON/OFF Zone Control – Suitable for hot or cold water flow in heating and cooling applications.
⦁ Versatile Applications – Controls fan coils, radiators, space heaters, and convectors.
⦁ Silent & Smooth Operation – Sinusoidal actuator travel reduces noise and water hammer.
⦁ Energy-Efficient – Actuator consumes power only while driving the valve to position.
⦁ Flexible Control Options – Compatible with low or line voltage SPST/SPDT controllers.
⦁ Easy Maintenance – Removable actuator head for quick replacement without draining the system.
⦁ Rugged & Reliable Design – Pressure differential up to 4 bar, high flow rate capacity, and long service life.
⦁ Quick Installation – Double-insulated actuator with quick-connect electrical connections.
